Gas – Fired Unit Heater Hermetic
GH 0860

Technical catalog
General Catalogue

Description

  • CE Certified, 1312CS6199.
  • High thermal efficiency by using the in-shot burner
  • Increase thermal surface with tubular heat exchanger
  • Durability and high corrosion resistance with aluminized steel heat exchanger
  • Washable body (stainless steel)
  • Fast heating with low noise axial fan
  • Gas control valve (SIT Group – ITALY)
  • Forced draft flue with centrifugal exhaust fan
  • Combustion air supply from outside (type C) or inside (type B)
  • Flue performance control with pressure switch
  • High Safety by thermostatic fan-limit control system
  • Heat exchanger overheating protection
  • Electronic board and Flame monitoring system
  • Automatic troubleshooting
  • User friendly (automatic ignition)
  • Low fuel consumption with thermostatic control system
  • Installation on Base or Hanging
  • Adjustable air damper
  • Natural gas (can be converted to LPG – as order)
  • Indoor Installation

Additional information

Specifications Unit GH0845 GH0845L
Fuel type – NG LPG
Fuel consumption m³/h 6.3 m³ 5 kg
Heat input Kcal/h 60000 58000
kW 70 67
Thermal efficiency % 85.5
Heat space (Approx.) m³ 1000-1200 1000-1100
Electrical A, V, ph 3,220,1
Sound level dB(A) 75
Airflow Cfm 3235
(m³/h) 6500
Throw m 12
Dimensions
(Height, Length, Width) 		cm 96×193×73
Nox class – 3
Weight (Gross) kg 168 +(12)
Flue diameter cm 15
Combustion air diameter cm 15
