Evaporative Cooler
EC 0350

Technical catalog
General Catalogue

Description

  • CE Certified, 801382008480
  • Evaporation efficiency of 85% using a special cellulose pad (4090 series)
  • Steady cooling efficiency by uniform distribution combi system of water on the cellulose pad during the season
  • Low electrical power consumption by using thermostatic control and cellulose pad
  • Reduce air pressure drop (reduce motor power consumption) by using cellulose pad
  • Automatic and manual operation
  • Control panel with remote and timer
  • Low electrical power consumption by using thermostatic control and cellulose pad
  • Special coating of industrial resin in cellulose pads: Reducing the growth bacteria
  • Reducing the transfer of harmful respiratory bacteria due to reduction of the transfer of tiny droplets of unevaporated water in the air flow
  • Safety control RCCB (Residual-Current Circuit Breaker) and Double-Pole Circuit Breaker
  • Long life cellulose pad (3 to 5 years)
  • Strong structure, low vibration and noise
  • Easily detachable
  • Strong structure, low vibration and noise

Additional information

Technical specifications Unit EC0350 EC0550 EC0700
Cooling system – Evaporative
Thickness pad cm 7.5
Cooling efficiency % 80 85
Air flow m³/h 3350 5900 8000
cfm 1970 3470 4700
Cooling area (Approx.) m² 30 – 60 65 – 90 90 – 130
Motor power hp 1/3 1/2 3/4
kW 0.25 0.37 0.5
Electrical A, V, ph 1.7,220,1 2.3,220,1 3.1, 220, 1
Weight + (water weight) kg 50+ (35) 74+(50) 86+(50)
Dimensions (Height, Length, Width) cm 80×75×75 99×90×90 111×90×90
Duct length (max) m 9 12 15
