Gas-Fired Unit Heater (Hermetic)
GH 0618

Technical catalog
General Catalogue

Description

  • CE Certified, 1312CS6199.
  • High thermal efficiency by using the in-shot burner
  • Increase thermal surface with tubular heat exchanger
  • Durability and high corrosion resistance with aluminized steel heat exchanger
  • Rust-resistant body with epoxy polyester coating
  • Fast heating with low noise axial fan
  • Gas control valve (SIT Group – ITALY)
  • Forced draft flue with centrifugal exhaust fan
  • Combustion air supply from outside (type C) or inside (type B)
  • Flue performance control with pressure switch
  • High Safety by thermostatic fan-limit control system
  • Heat exchanger overheating protection
  • Electronic board and Flame monitoring system
  • Automatic troubleshooting
  • Low fuel consumption with thermostatic control system
  • Ability to install on base and wall
  • Natural gas (can be converted to LPG – as order)
  • Indoor Installation



   Note1:    GH 0845G: Suitable for high-humidity environments (e.g. Greenhouses)

    Note2: L: LPG

Additional information

Specifications Unit GH0618 GH0618L GH0825 GH0825L GH0845 GH0845L
Fuel type – NG LPG NG LPG NG LPG
Fuel consumption m³/h 1.9 m³ 1.5 kg 2.7 m³ 2 kg 4.8 m³ 3.8 kg
Heat input Kcal/h 18000 25000 45000
kW 21 29 52
Thermal efficiency % 81.5 81.5 84
Heat space (Approx.) m³ 200-360 400-700 700-900
Electrical A, V, ph 1,220,1
Sound level dB(A) 53 59 55
Air flow Cfm 883 2060 2060
(m³/h) 1500 3500 3500
Throw m 6 9 12
Dimensions
(Height, Length, Width) 		cm 51.5×76.5×60.5 59×89×66 70×100×67
Nox class – 3
Weight (Gross) kg 48+3 69+15 84+16
Flue diameter cm 10 10 15
Combustion air diameter cm 10 10 15
